    High Efficiency 5000m Detection Distance Radio Technology UAV Scanning and Jamming System

    Ask Lasest Price
    Brand Name : EST
    Model Number : UAV-J2020
    Certification : CE&ROHS
    Delivery Time : 7-10 working days
    Payment Terms : 100% before shipment, Western Union, T/T
    Supply Ability : 500pcs/week
    • Product Details
    • Company Profile

    High Efficiency 5000m Detection Distance Radio Technology UAV Scanning and Jamming System

    EST-GSM DCS Dual band Mobile Phone Signal Repeater/Amplifier/Booster

    High Efficiency 5000m Detection Distance Radio Technology UAV Scanning and Jamming System


    1. System Characteristics

    1.Integrated detection and interference, smaller, lighter;
    2.Passive passive detection, 360° omni-directional, 50 MHz-6GHz ultra-wide spectrum detection range;
    3.With the ability of independent learning to identify unknown UAV, can record its signal characteristics in UAV flight, including standard broadband map transmission and frequency jump map transmission of industrial UAV, consumer UAV, patent design, the world's first;
    4.AOA single-station identification and positioning UAV;
    5.It can handle more than 10 targets at the same time to detect and identify the positioning and interference;
    6.All-day, all-weather, unattended;
    7.Multi-antenna array design, suitable for the city's particularly complex electromagnetic environment, suburban environment detection up to 5000M;
    8.Open the UAV signal feature recording, for the new UAV, the model can be identified after recording;
    9.With the whitelist function;
    10.Unique intelligent gain and reference level patent design, to meet the needs of complex electromagnetic environment detection;
    11.Directional countermeasures, do not cause too much impact on other communication, high efficiency, low RF power;
    Special frequency hopping signal recognition technology can distinguish multiple remote controls and industrial frequency hopping UAV;


    2. System Parameter

    The main technical parameters of the UAV detection and jamming system are shown in the following table:

    DetectionFrequency Range50MHz ~6GHz
    Detection Radius5000m (depending on the working condition)
    Real-time Broadband Processing160MHz
    Ranging Accuracy≤10%R
    Horizontal Extent0-360°
    JammingFrequency Band 1(895~935) ± 5 MHz / 25W
    Frequency Band 2(1165~1285) ± 5 MHz / 10W (PRO version optional)
    Frequency Band 3(1555~1635) ± 5 MHz / 10W
    Frequency Band 4(2395~2505) ± 5 MHz / 25W*2
    Frequency Band 5(5130~5395) ± 5 MHz / 50W (PRO version optional)
    Frequency Band 6(5730~5865) ± 5 MHz / 25W*2
    Frequency Band 7(433) (PRO version is optional)
    Shielding Distance1000m-2000m
    Response Time≤3s
    Operating SystemWhite Listpossess
    Unattended Operationpossess
    Data Storage, Historical Track Playbackpossess
    Signal Recordingpossess
    Mono Station Locatingpossess
    Sound and Light Alarm Functionpossess
    Tractor ParameterLevels of ProtectionLevel IP65
    SizeHigh Efficiency 5000m Detection Distance Radio Technology UAV Scanning and Jamming System=500mm, H=500mm
    Weight15KG
    Maximum Power Dissipation

    Detection 60W;

    band countermeasures <750W

    Working Temperature-30°-60°

    3. System Deployment

    6.1 Single-station System Deployment
    The UAV detection and countermeasures system can complete the 360° range of omnidirectional scanning and directional interference alone, and build an all-weather UAV no-fly zone. You can roughly obtain the location and distance information of the UAV by single station deployment. The deployment diagram of the single station system is as follows:


    6.2 Multi-station Network Deployment
    The deployment of multiple stations (2 stations) can give the location of the UAV through cross-positioning mode. Each site can perform both a routine signal monitoring task and an AOA cross-localization. AOA cross-mapping is a method of orientation crossing for mapping. By measuring the position determination of the two direction crossing, we can track the UAV flight information in real time in the area where the source is located. During unattended work, different stations can strike a single target at the same time, and the strike efficiency is higher. The multi-station network deployment schematic diagram is as follows:
